SIEMENS 6ES7223-1PL32-0XB0 SIMATIC S7-1200, DIGITAL I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC, SINK/SOURCE, 16 DO, RELAY 2 A

Name: SIEMENS 6ES72231PL320XB0 SIMATIC S71200 DIGITAL IO SM 1223 16 DI16 DO 16 DI 24 V DC SINKSOURCE 16 DO RELAY 2 A
Brand: SIEMENS
Price: 1 USD

SIEMENS 6ES7223-1PL32-0XB0 SIMATIC S7-1200, DIGITAL I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC, SINK/SOURCE, 16 DO, RELAY 2 A

Categories	PLC SIMATIC S7-1200
Brand Name:	SIEMENS
Model Number:	6ES7223-1PL32-0XB0
Certification:	CE
Place of Origin:	Germany
MOQ:	1
Price:	USD
Payment Terms:	L/C, T/T
Supply Ability:	100PS
Delivery Time:	10-12Days
Packaging Details:	8,80 x 11,00 x 8,50CM
Programming Software:	STEP 7 Basic V14
Model:	SM1222 16 X RELAY
Analog Outputs:	2 (0-10 V DC)
Number Of Digital Inputs:	8/16/24/32/40
Ambient Temperature:	-25 to +60 °C
Integrated Safety:	Yes
Certifications:	CE, UL, cUL, FM, RCM, KC
Digital Outputs:	16 (24 V DC)
Integrated Diagnostics:	Yes
Mounting:	Rack or DIN Rail
Integrated Motion Control:	Yes
Programming Languages:	Ladder Logic, Function Block Diagram, Structured Text
Cpu:	1212C, 1211C,1214C, 1215C, 1217C
Integrated Hmi:	Yes
Cpu Type:	S7-1200

Contact Now

Add to Cart

Company Info.

Shenzhen Voboal Industrial Automation Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

SIEMENS 6ES7223-1PL32-0XB0 SIMATIC S7-1200, DIGITAL I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC, SINK/SOURCE, 16 DO, RELAY 2 A

The **Siemens 6ES7223-1PL32-0XB0** is a **Simatic S7-1200** Digital Input/Output module, specifically the SM 1223 variant. This module combines 16 digital inputs and 16 digital outputs in one unit.

Here are the key specifications for this Digital I/O module:

- **Product Code:** 6ES7223-1PL32-0XB0
- **Product Name:** SIMATIC S7-1200 Digital I/O SM 1223
- **Module Type:** Digital Input/Output module
- **Digital Inputs:** 16 inputs at 24 V DC, sink/source configurable
- **Digital Outputs:** 16 outputs with relay contacts, capable of handling up to 2 A
- **Input Type:** 24 V DC
- **Output Type:** Relay contacts

### Overview:
- **Module Type:** Digital Input/Output module suitable for the S7-1200 series
- **Digital Inputs:** Provides 16 digital inputs that can be configured as sink/source at 24 V DC
- **Digital Outputs:** Offers 16 digital outputs with relay contacts capable of handling up to 2 A
- **Input/Output Configuration:** Combines both digital input and output capabilities in one module
- **Application:** Ideal for applications requiring a larger number of digital input and output signals with relay switching

The Siemens 6ES7223-1PL32-0XB0 SM 1223 Digital Input/Output module is a reliable component designed for industrial automation applications within the Simatic S7-1200 series. With its combination of 16 digital inputs and 16 digital outputs featuring relay contacts, this module is suitable for applications where a larger number of input and output signals need to be managed within the same unit using a 24 V DC power supply.

Product
Article Number	6ES7223-1PL32-0XB0
Product Description	SIMATIC S7-1200, Digital I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC, Sink/Source, 16 DO, relay 2 A
Product family	SM 1223 digital input/output modules
Product Lifecycle (PLM)	PM300:Active Product
Price data
Price Group	212
List Price	Show prices
Customer Price	Show prices
Surcharge for Raw Material	see also metal factor (further details are available on the help page)
Metal Factor	see also metal factor (further details are available on the help page)
Delivery information
Export Control Regulations	AL : N / ECCN : N
Estimated dispatch time (Working Days)	1 Day(s)
Net Weight (kg)	0,319 Kg
Packaging Dimension	8,80 x 11,00 x 8,50
Package size unit of measure	CM
Quantity Unit	1 Piece
Packaging Quantity	1
Additional Product Information
EAN	6940408102019
UPC	887621206949
Commodity Code	85389091
LKZ_FDB/ CatalogID	ST72
Product Group	4508
Group Code	R132
Country of origin	Germany
