Dual-Table CNC Precision Metal Seam Rolling & Corner Pressing Machine

Categories Cookware Production Line
Brand Name: Star Power
Model Number: MSP-3000Pro
Certification: CU, ISO
Place of Origin: Guangdong, China
MOQ: 1 set
Price: Negotiable
Payment Terms: L/C,T/T
Supply Ability: 30 Set/Sets per Year
Delivery Time: 30-50 working days
Packaging Details: Seaworthy Packing
Energy Consumption: Low
Voltage: 380V/220V Optional
Application: Cookware Manufacturing
Dimention: 12700mm×1730mm×2400mm (L×W×H)
Control System: PLC
Production Process: Feeding - Forming - Welding - Polishing - Inspection - Packaging
Customization: Available
Product Type: Production Line
Power: 100kw, 300KHz, 380V/440V
Safety: High
Machine Weight: About 2.8T
Machine Size: 2800mm×1500mm×3200mm (L×W×H)
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Dual-Table CNC Precision Metal Seam Rolling & Corner Pressing Machine

Dual-Table CNC Precision Metal Seam Rolling & Corner Pressing Machine
Dual-Table CNC Precision Metal Seam Rolling Machine in operation
Key Specifications
AttributeValue
Energy ConsumptionLow
Voltage380V/220V Optional
ApplicationCookware Manufacturing
Dimension12700mm×1730mm×2400mm (L×W×H)
Control SystemPLC
Production ProcessFeeding - Forming - Welding - Polishing - Inspection - Packaging
CustomizationAvailable
Power100kw, 300KHz, 380V/440V
Machine WeightAbout 2.8T
Product Overview

The MSP-3000Pro Dual-Table CNC Precision Metal Seam Rolling & Corner Pressing Machine is a state-of-the-art industrial equipment engineered for high-precision metal fabrication processes. This advanced machine integrates dual-worktable functionality with computer numerical control to deliver exceptional efficiency, accuracy, and versatility in seam rolling and corner pressing applications across various manufacturing sectors.

Mechanical Structure & Design
  • Dual-Tilting Worktables: Features two independently adjustable metal worktables (480×360mm each) with a tilting range of 0-90°, enabling simultaneous loading/unloading and continuous production workflow.
  • Precision Mechanical Arm: Robotic-grade horizontal sliding arm with ball screw drive system, offering positional accuracy of ±0.02mm and repeatability of ±0.01mm.
  • Heavy-Duty Frame: Welded steel construction with blue powder-coated finish providing structural rigidity and vibration dampening.
  • Integrated Lighting System: Articulating LED gooseneck lamp with brightness adjustment for enhanced workpiece visibility.
Close-up of machine's control panel and work area
Technical Specifications
  • CNC Control System: Industrial-grade PLC with 7-inch color touchscreen HMI
  • Axis Configuration: 3-axis servo control with 1000mm/min rapid traverse speed
  • Processing Capacity: Mild steel (up to 4mm), stainless steel (up to 3mm), aluminum alloys (up to 5mm)
  • Power Requirements: AC 380V ±10%, 50Hz, 3-phase, 4.5kW maximum
Operational Features
  • Semi-Automatic Mode combines automated tool movement with manual workpiece loading
  • Quick-release tooling system allowing die changes in under 2 minutes
  • Safety features including dual-hand start buttons and emergency stop circuit
  • Real-time error monitoring with on-screen troubleshooting guides
Applications

Designed for precision metal fabrication in industries including: electrical enclosure manufacturing, automotive component production, HVAC ductwork fabrication, kitchenware manufacturing, and furniture hardware production.

Customer Benefits
  • Quality Upgrade: Precise grinding improves product details, enhancing market competitiveness.
  • Cost Reduction & Efficiency: Automated operation reduces labor costs while increasing production capacity.
  • After-Sales Support: 7x24 technical support, free installation and commissioning, and 1-year warranty.
Machine schematic and dimensions
