Intel ® J6412 cpu 4*2.5G LAN 6 USB Firewall appliance pFsense soft router fanless mini industry pc

Contact Now

Add to Cart

Company Info.

SHENZHEN VEGASHINE TECHNOLOGY CO.,LIMITED

View Contact Details

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Key Features

Aluminium alloy chassis

Celeron® J6412 quad-core quad-thread, main frequency: 2.00GHz

2×DDR4 260PIN SO-DIMM slots, support DDR4 3200, single stick max 32GB

1×SATA 3.0

1×M.2 (NVMe protocol),

1×RJ45 COM port

1×DP+HD interface

DC 12V-4A, 5.5×2.5mm barrel jack

Package Dimensions 20 × 17 × 12 (cm)

Specifications

Model No.	VGS-BF1604003HD-J6412
Chassis Color	Black
Material	aluminium alloy chassis
Installation	Desktop
Processor	Celeron® J6412 quad-core quad-thread, main frequency: 2.00GHz
Chipset	Intel® J6412 (optional J6413)
BIOS	AMI EFI BIOS
Memory	2×DDR4 3200MHz notebook memory slots, max. 32GB, SODIMM
Storage	1×M.2 (NVMe protocol), 1×SATA 3.0
Graphics	Integrated Intel® HD Graphics 600
Display Interfaces	1×HDMI + 1×DP, supporting synchronous/asynchronous display
Front I/O Ports	4×2.5G Ethernet ports, 1×DC power adapter port
Rear I/O Ports	1×USB3.0, 5×USB2.0, 1×HDMI (with audio output), 1×DP, 1×power button, 1×power/HDD LED indicator, 1×clr-cmos button, 1×4G SIM slot, 1×5G SIM slot
Expansion Slots	1 full-length MINI-PCI-e (supports USB-signal 3G/4G modules), 1×M.2 2242 (supports 5G modules)
Network Interfaces	4×Intel® I226 Gigabit Ethernet NICs, supporting diskless boot and Wake-on-LAN
Other Features	Power-on at power restore, scheduled power-on, Wake-on-LAN, PXE boot, watchdog timer
Power Supply	DC 12V-4A, 5.5×2.5mm barrel connector
Safety Certifications	CE, CCC, FCC, RoHS
Dimensions	136 × 126 × 40 (mm)
Weight	1.25 kg (complete unit), 0.75 kg (barebone unit)
Package Dimensions	20 × 17 × 12 (cm)
Operating Temperature	0 ~ +50℃(with commercial HDD), -20℃~ +50℃(with industrial SSD), with air flow
Humidity	5 ~ 90% relative humidity, non-condensing
Operate System	Support Pfsense ,Linux, iKuai, LEDE, Openwrt, Panabit, Smart6, Win 7/8/10 etc.
